G406-4 Series ELT Replacement Battery Pack | Lithium, 5 Year

$846.65

The Artex replacement battery pack for the G406-4 ELT consists of four “D” size lithium manganese dioxide cells connected in series. In an effort to increase the safety of the battery pack, a number of features were designed into the battery pack. To prevent the cells from being charged, diodes are connected across each cell and fuses are connected to the output.

Lithium (LiMnO2, solid cathode)
5 year rated
Assembly is high impact, fire resistant polycarbonate plastic
Replacement for the ACR Artex G406-4 series ELT

Product Codes
Mfr Part No :	452-0222
ECCN :	7A994
NSN :	6130-01-531-3836
PROAPP :	PT1113CE/PQ1113CE
SCHEDULE B CODE :	8506.80.0000
TSO :	C91a,C126 THIS PART IS A SUBCOMPONENT OF A FAA TSO ARTICLE
UN ID# :	3090, Lithium metal batteries
